Teledyne DALSA’s Z-Trak Laser Profiler Series Excels at In-Line Measurement and Inspection Operations

Teledyne DALSA, a Teledyne Technologies company and international player in machine vision technology, has incorporated to its proven 1D and 2D camera portfolio, the new, high-accuracy 3D laser profiler series for industrial imaging and factory automation.

Teledyne DALSA’s newly released Z-Trak 3D laser profiler. (Image credit: Teledyne DALSA)

The Z-TrakTM LP1 series of 3D laser profilers offer precise and accurate height measurements in an ergonomically engineered compact unit, with a robust FIR-peak detector. Z-Trak LP1 series profilers are factory-calibrated and packaged with Teledyne DALSA’s Sapera Processing 8 Runtime, or Sherlock 8 3D software for easy installation and deployment. Furthermore, the LP1 series comprises of a GigE Vision® interface, support the GenICam® standard, and can be easily interfaced with other off-the-shelf software. The Z-Trak supports Power-over-Ethernet (PoE) and consists of all-purpose inputs/outputs and versatile mounting options.

The Z-Trak laser profilers are suitable for in-line metrology, parts inspection and identification, volumetric measurements, and bin-picking applications for semiconductor, factory automation, electronics, and logistics.

The Z-Trak series is feature rich and cost-effective, with a powerful technological foundation. This strong foundation is critical not only to achieve superior results, but sets the stage for future innovations around our advanced sensor and software capabilities.

Ghislain Beaupré, Vice President and GM, Teledyne DALSA.

Key Features

  • Compact IP67 housing for tough operating environment
  • Strong FIR-Peak detector algorithm delivers stable operations and high accuracy
  • High accuracy with both blue and red lasers
  • Enables imaging of objects with diverse surface reflectance
  • Enhanced optical path guarantees consistent results across the whole measurement range
  • Available in laser class 2M and 3R for broad operating settings
  • Broad selection of models:  measurement range between 10 mm and 1000 mm
  • Z-Trak includes well-established Sapera™ LT, Sapera Processing Group 1 RTL, and Sherlock™ 8.0 3D

The new Z-Trak laser profiler will be showcased in “live” demonstrations at these shows:

  • Automate 2019
  • Vision China Shanghai
  • Control 2019 Germany
  • Automation World Korea
