Specialty Optical Glass & Materials for Defence Imaging

By Ankit SinghReviewed by Susha Cheriyedath, M.Sc.Apr 16 2026

Defence imaging systems demand materials that can perform reliably across extreme environments, wide temperature swings, and hostile field conditions. The optical glass and crystalline materials used in these systems are crucial because they affect image clarity, range, and reliability of thermal surveillance cameras and missile guidance sensors.

Image Credit: Fuad_Naser_Bondhon/Shutterstock

Engineers select materials based on transmission range, mechanical durability, refractive properties, and thermal stability.  This article explores the optical properties, structural characteristics, and strategic significance of the primary glass and crystalline materials used across modern defence imaging platforms.

The Optical Foundation of Defence Imaging

Optical materials used in defence imaging cover a wide range of the electromagnetic spectrum, from ultraviolet (UV) and visible light through mid-wave infrared (MWIR) and long-wave infrared (LWIR) bands. Different spectral regions serve distinct tactical purposes.

For example, visible-band optics support daylight observation, while infrared optics are used for thermal detection for night vision, target acquisition, and surveillance. Because no single type of glass transmits equally well across all wavelengths, specific materials are chosen based on their unique properties. The core parameters that guide material selection for a given imaging task are refractive index, Abbe number, and spectral transmission cutoff.^1,2

Saving this for later? Download a PDF here.

Defence platforms also require materials that maintain optical alignment under mechanical shock, vibration, and abrupt temperature changes. Military optics mounted on armored vehicles, aircraft, or dismounted sighting systems must retain focus and transmission accuracy under operational stress.

Low coefficients of thermal expansion, high compressive strength, and surface resistance to environmental degradation determine a material's fitness for these roles. The combination of optical and mechanical requirements narrows options, making each specialized material a critical design choice.^3,4

Germanium in Long-Wave Infrared Systems

Germanium is the most widely used crystalline material for LWIR defence optics and delivers peak transmission in the 8 to 12 µm thermal band. Its high refractive index allows designers to achieve wide fields of view with fewer lens elements, reducing system size and weight in compact thermal cameras. Germanium also has low optical dispersion, which provides clear, high-contrast thermal imagery in forward-looking infrared systems and border surveillance platforms. These properties made germanium the backbone of thermally sensitive military imaging for decades.^5,6

Despite its strong optical profile, germanium carries significant operational limitations. A thermal runaway effect causes transmission to decrease as temperature rises. This restricts germanium optics to systems operating below 100°C. Moreover, its high density of 5.33 g/cm³ adds weight to payload configurations in unmanned aerial vehicles (UAVs) and soldier-carried systems.^5,6

Chalcogenide Glass as a Strategic Alternative

Chalcogenide glasses are compounds of sulfur, selenium, or tellurium. It transmits broadly across the 3 to 5 µm and 7 to 14 µm infrared bands, covering both MWIR and LWIR regions. Chalcogenide glass can be precision-molded into complex lens shapes in a single manufacturing cycle, unlike crystalline germanium.

This process reduces production costs and results in compact optical assemblies. Its low thermo-optic coefficient minimizes focus shift across a wide temperature range, supporting passively athermal lens designs critical for airborne and ground-based surveillance systems.⁷

Chalcogenide glass is a special type of material that can be treated with a hard diamond-like carbon, which makes it strong and resistant to chemicals. Recently, it has become a popular choice for infrared technology used in thermal imaging systems. This shift comes as the costs of germanium, another material commonly used for these purposes, rise, and concerns about its availability grow due to geopolitical issues.

Chalcogenide glass is easier to shape and produce in large quantities, avoiding the supply problems associated with sourcing germanium. As a result, it is seen as a dependable and efficient option for long-term defence contracts.^8,9

Sapphire for Frontline Optical Protection

Sapphire is a tough material often used in defence applications to protect soft optical surfaces from wear, high pressure, and impacts. It has a hardness rating of 9 on the Mohs scale, making it highly scratch-resistant to elements like sand and dust. It transmits from approximately 150 nm in the ultraviolet through 5.5 µm in the mid-infrared, which means a single sapphire window can be used for various imaging purposes without needing multiple components.^6,10

Sapphire's robustness makes it the standard material for missile nose domes, panoramic imaging masts, gimbal windows, and armored vehicle periscopes. It can handle extreme temperatures of up to 1000°C and endure high pressure without losing its optical clarity.^6,10

With anti-reflective coatings applied to both surfaces, sapphire can transmit up to 99% of light, enabling near-lossless light collection for precision reconnaissance and targeting systems. Lastly, sapphire's density of 3.95 to 4.03 g/cm³ provides a favorable strength-to-weight ratio compared to conventional glass, especially for airborne applications.¹¹

Zinc-Based Infrared Materials

Zinc selenide (ZnSe) and zinc sulfide (ZnS) occupy complementary roles in military thermal and multispectral imaging. ZnSe transmits across visible and IR bands with minimal absorption loss and maintains a uniform refractive index that delivers consistent image quality in forward-looking infrared (FLIR) imaging. Its low scattering and stable optical properties make it well-suited for protective windows and detector lenses mounted on vehicles, naval platforms, and fixed surveillance installations.^12,13

Zinc sulfide is produced in two special grades for defence applications. The FLIR grade is designed for thermal imaging with high durability and chemical resistance. The multispectral grade supports dual-mode imaging architectures and transmits from 370 nm to beyond 12 µm. It is used in dual-mode imaging architectures that integrate visible and infrared sensor coverage within a single aperture, a configuration increasingly adopted in modern multi-sensor defence platforms.^13,14

Protective Coatings and System Performance

Optical coatings improve the transmission properties of glass and crystals, ensuring they perform effectively in real-life situations. Anti-reflective coatings on silicon, germanium, and chalcogenide glass reduce surface reflections. This boosts signal strength and enhances image quality in thermal and night vision systems.

Special four-layer anti-reflection coatings made of ZnS and YF₃ thin films are designed for HgCdTe-based MWIR detectors. These coatings are tailored to fit specific detector designs, material substrates, and target spectral bands.¹⁵

Diamond-like carbon (DLC) coatings applied to germanium or silicon optics meet military standards for environmental protection. These coatings guard surfaces against wear, moisture, and corrosion during long field operations. DLC coatings are optimized for performance in specific infrared windows and sustain their protective properties through thermal cycling without degrading transmission. Multispectral coatings spanning UV, visible, SWIR, MWIR, and LWIR bands extend the imaging reach of large reflective optics deployed in airborne and space-based defence surveillance systems.^16,17

References and Further Reading

1. Vizgaitis, J. N. et al. (2016). Advanced Optics for Defense Applications: UV through LWIR. SPIE DEFENSE + SECURITY, Proceedings of SPIE. Vol. 9822. DOI:10.1117/12.2244400. https://www.spiedigitallibrary.org/conference-proceedings-of-spie/9822.toc
2. Jun, B. H. (2023). Advanced Optical Materials: From Materials to Applications. International Journal of Molecular Sciences, 24(21). DOI:10.3390/ijms242115790. https://www.mdpi.com/1422-0067/24/21/15790
3. Koerber, J. et al. (2023). Advanced optics for EO/IR applications. Proceedings Volume 12665, Novel Optical Systems, Methods, and Applications. DOI:10.1117/12.2677684. https://www.spiedigitallibrary.org/conference-proceedings-of-spie/12665/2677684/Advanced-optics-for-EOIR-applications/10.1117/12.2677684.short
4. Ellis, A. (2025). Multispectral glasses and coatings for defence applications. University of Southampton. DOI:10.1117/12.2663345. https://eprints.soton.ac.uk/501912/
5. IR Lenses. Paras Defence. https://parasdefence.com/product-detail-3?type=ir-lenses
6. Rowe, S. (2024). What optical materials work best in the IR (infrared)? ESCO Optics. https://escooptics.com/blogs/news/what-optical-materials-work-best-in-the-ir-infrared
7. Athermal Infrared Lens Design Using Chalcogenide Glass for LWIR Cameras. Avantier Inc. https://avantierinc.com/resources/case-study/chalcogenide-glass-infrared-lens-design/
8. Musgraves, J. D. (2024). Chalcogenide glasses: Engineering in the infrared spectrum. Bulletin. https://bulletin.ceramics.org/article/chalcogenide-glasses-engineering-in-the-infrared-spectrum/
9. Biggs, K. (2026). Chalcogenide Glass As A High-Performance Alternative to Germanium for Infrared Optics. UQG Optics. https://www.uqgoptics.com/chalcogenide-glass-as-a-high-performance-alternative-to-germanium-for-infrared-optics/
10. Rowe, S. (2026). Sapphire optical properties. ESCO Optics. https://escooptics.com/blogs/news/what-optical-materials-work-best-in-the-ir-infrared
11. Sapphire windows: properties and advantages. (2023). Wintech Groupe. https://wintech-groupe.com/en/news/sapphire-windows-properties-and-advantages/
12. ZnSe vs. ZnS Windows: Choosing the Right IR Material for 2026 Defense and Medical Systems. (2026). Hyperion Optics. https://www.hypoptics.com/znse-vs-zns-windows-choosing-the-right-ir-material-for-2026-defense-and-medical-systems.html
13. Klein, C. A. et al. (1986). ZnS, ZnSe, and ZnS/ZnSe windows - Their impact on FLIR system performance. Optical Engineering, 25(4). https://wp.optics.arizona.edu/optomech/wp-content/uploads/sites/53/2016/10/Klein-1986.pdf
14. ZnS / Zinc Sulfide IR optical component: a complete guide. Sinoptix. https://sinoptix.eu/zinc-sulfide-ir-optical-component-guide/
15. Meena, V. S. et al. (2023). Design and development of four-layer anti-reflection coating stacks (ZnS and YF3 thin films) for HgCdTe-based mid-wave infrared detectors. Materials Science in Semiconductor Processing, 163, 107556. DOI:10.1016/j.mssp.2023.107556. https://www.sciencedirect.com/science/article/abs/pii/S1369800123002494
16. Rajak, D. K. et al. (2021). Diamond-Like Carbon (DLC) Coatings: Classification, Properties, and Applications. Applied Sciences, 11(10). DOI:10.3390/app11104445. https://www.mdpi.com/2076-3417/11/10/4445
17. Guo, S. et al. (2020). Past Achievements and Future Challenges in the Development of Infrared Antireflective and Protective Coatings. Physica Status Solidi (a), 217(16), 2000149. DOI:10.1002/pssa.202000149. https://onlinelibrary.wiley.com/doi/abs/10.1002/pssa.202000149
