Quantum ghost imaging powered by natural sunlight generated correlated photon pairs and high-visibility images, showing how laser-free optical setups could support sustainable sensing and space-based quantum communications in future networks.
Study: Sunlight-excited spontaneous parametric down-conversion for ghost imaging. Image Credit: atdigit /Shutterstock
A recent study published in the journal Advanced Photonics demonstrated a novel method for generating position-correlated photon pairs using natural sunlight to power a ghost imaging system. Researchers showed that an incoherent broadband natural light source can effectively replace conventional lasers in quantum illumination experiments, marking a significant step toward sustainable quantum technology development.
By using sunlight, the system eliminates the need for artificial power supplies while achieving 90.7% image visibility. This finding connects classical and quantum optics and could support sustainable remote sensing and space-based quantum communication systems.
Innovations in Ghost Imaging Techniques
Ghost imaging is an optical sensing technique that reconstructs an object's image using photons that never directly interact with it. It divides a light source into two paths: in the signal arm, light illuminates the target object and is collected by a pixel bucket detector, while in the idler arm, a spatial detector records the profile of the reference beam. An image is reconstructed by calculating intensity or photon coincidence between both paths.
Conventional ghost imaging systems often rely on highly coherent laser sources that drive spontaneous parametric down-conversion (SPDC) in nonlinear crystals to generate correlated or entangled photon pairs. Although approaches using pseudo-thermal light and particles such as electrons or neutrons have been explored, generating high-visibility quantum ghost images with a fully incoherent natural light source has remained a challenge.
Experimental Setup for Sunlight-Driven Imaging
To achieve down-conversion without a laser source, researchers developed a solar-tracking system based on an equatorial-mount design. This system automatically adjusts its pitch angle using real-time geographic positioning and a photosensitive sensor to maintain alignment with the sun. Sunlight is collected through a 10-cm-diameter Fresnel lens and transmitted via a 20-m plastic multimode optical fiber into an indoor darkroom lab.
Inside the experimental setup, a microscope objective collimates the incoming sunlight before focusing it onto a periodically poled potassium titanyl phosphate (PPKTP) nonlinear crystal. Before reaching the crystal, the beam passed through an aperture that reduced its diameter to 0.8 mm. A linear polarizer and a 10 nm spectral filter centered at 405 nm prepare the sunlight pump while preserving its short transverse coherence length. For comparison experiments, a 405 nm laser can also be coupled into the same optical system.
After the nonlinear crystal, a long-pass filter removes the remaining pump light, allowing only the down-converted photon pairs to propagate through a 4f imaging system. A polarizing beam splitter then separates the photons into signal and idler paths. The vertically polarized signal photons pass through either a double slit object or a ghost face mask before entering a single-photon detector. Simultaneously, the horizontally polarized idler photons enter the reference arm, where a matching fiber records the spatial distribution. A coincidence counting device detects correlated photon pairs using a 1 ns timing window.
Performance Evaluation and Results
The sunlight-driven down-conversion process demonstrated strong stability despite natural variations in solar intensity. During a continuous observation period from 9 a.m. to 3 p.m., the solar pump power reaching the nonlinear crystal peaked at approximately 3 μW on clear days. Under type II collinear phase-matching conditions, this weak optical pump generated a measurable flux of position-correlated photon pairs. The coincidence-to-single-count ratio stabilized at approximately 0.22%, comparable to earlier light-emitting diode-based systems.
Download the PDF of this page here
To verify that the detected correlations originated from quantum down-conversion rather than background sunlight, the initial polarizer was rotated into a phase-mismatched orientation, causing the coincidence count rate to drop significantly and confirming a phase-matching contrast ratio of about 97.6%. Measurements of the joint probability distributions showed a clear positive diagonal correlation in position space, confirming that the short transverse coherence length of sunlight did not destroy the spatial correlations between photon pairs.
In the double slit experiment using a slit spacing of 0.75 mm and a slit width of 0.15 mm, the setup achieved an image visibility of 90.7%, close to the 95.5% visibility measured with the laser pump. For the two-dimensional (2D) ghost face imaging experiment, data collected over 10 days reduced random fluctuations, yielding an average coincidence-to-accidental ratio of approximately 108 within the target region. These results confirm that the reconstructed image originated from genuine two-photon coincidences.
Potentials for Quantum Communication
The successful demonstration of sunlight-driven ghost imaging has important implications for future aerospace telemetry and space-based quantum communication systems. By utilizing naturally available solar radiation, orbital quantum platforms could significantly reduce dependence on large laser systems and high-power electrical infrastructure.
This approach could also support self-sustained satellite-to-satellite and satellite-to-ground quantum key distribution networks. Additionally, partially coherent down-converted photon pairs may offer improved resistance to atmospheric turbulence and thermal fluctuations, making them suitable for secure optical communication and remote planetary sensing.
Conclusion and Future Directions
In summary, this study provides proof that natural sunlight can successfully drive quantum parametric down-conversion systems. Although the initial setup required long image acquisition times due to low microwatt-level pump power, it identified several routes for improving system performance. Larger solar collectors and shorter low-loss optical fibers could increase the pump power into the milliwatt range, allowing for faster imaging.
Moving forward, researchers suggested combining their technique with broadband nonlinear crystal waveguides, compressed sensing methods, and deep learning (DL) based image reconstruction. Overall, these developments could effectively support high-visibility quantum imaging systems for large-scale terrestrial and space-based applications.
Journal Reference
Xing, Y., & et al. (2026). Sunlight-excited spontaneous parametric down-conversion for ghost imaging. Advanced Photonics, 8, 3, 036011. DOI: 10.1117/1.AP.8.3.036011, https://www.spiedigitallibrary.org/journals/advanced-photonics/volume-8/issue-03/036011/Sunlight-excited-spontaneous-parametric-down-conversion-for-ghost-imaging/10.1117/1.AP.8.3.036011.full
