Sulfur Polymer Optics for Infrared Thermal Imaging

By Dr. Noopur JainReviewed by Louis CastelMar 25 2026

In a recent article published in the journal Nature Communications, researchers explored the development of a novel sulfur-based polymer lens for thermal imaging optics that combines a high refractive index (n ≈ 1.87), measurable long-wave infrared (LWIR, 7–14 μm) transparency, and intrinsic recyclability, while also resolving a previously unsynthesizable predicted polymer structure.

Image Credit: Igor Kyrlystya/Shutterstock.com

Rethinking Infrared Optics

Infrared thermal imaging is a critical technology used across various fields including defense, security, fire detection, planetary science, automotive driver assistance, and medical thermography. However, conventional infrared camera lenses rely on materials such as germanium, silicon, and chalcogenide glass, which are expensive, have restricted availability, and require complex low-throughput milling for shaping. These issues restrict widespread usage and scaling, especially for customized prescriptions. To address these challenges, there is a pressing need for cost-effective, sustainable, and rapidly manufacturable lens materials that maintain optical performance in the LWIR region.

Sulfur-rich polymers derived from elemental sulfur have attracted attention as promising candidates for infrared optics due to their high refractive indices and transparency in mid-wave (MWIR) and long-wave infrared regions. Previous efforts have demonstrated such polymers’ utility for infrared windows, lenses, photonic crystals, waveguides, and infrared polarizers. These polymers benefit from their low cost, abundance of sulfur, and dynamic sulfur-sulfur (S–S) bonds that enable molding and self-healing. However, most sulfur polymers previously reported exhibit limitations including insufficient LWIR transmittance and low glass transition temperatures, which hamper shape persistence and performance under operating conditions.

Notably, earlier theoretical work predicted an optimal sulfurized norbornane polymer structure, but it could not be synthesized directly due to side reactions forming cyclopropane-containing units that degraded LWIR transparency.

Designing a Previously Inaccessible Sulfur Polymer

The study designed and synthesized a sulfur polymer containing a sulfurized norbornane microstructure to achieve high LWIR transmission and thermal stability. Crucially, instead of direct inverse vulcanization of norbornadiene, the researchers employed a redesigned synthetic route using pre-sulfurized monomers to access the previously inaccessible target polymer structure (“polymer 1”). The synthesis involved carefully controlled inverse vulcanization reactions of elemental sulfur with these tailored monomers, yielding a polymer containing approximately 81% sulfur by mass.

The polymer was synthesized by heating and degassing sulfur before adding the monomer, followed by curing in silicone molds to generate optical-quality windows and lenses. Optical lenses were prepared both by casting using custom silicone molds and by reactive compression molding, enabling rapid manufacturing of multiple lenses simultaneously. The reactive compression molding process consolidated polymer particles through thermally-induced S–S metathesis under heat and pressure, producing monolithic lens arrays with high optical quality and no visible defects.

The resulting lenses were characterized for infrared transparency, refractive index, thermal stability, and imaging performance on commercial LWIR camera modules such as the FLIR Lepton 3.5. Standard polishing methods were applied to achieve smooth optical surfaces.

Bridging Performance and Manufacturability in Sulfur Polymer Optics

The newly synthesized sulfur polymer lenses exhibited measurable LWIR and MWIR transparency, with a 1.0 mm thick window showing average transmission values of approximately 48.6% in the MWIR and 19.4% in the LWIR region, representing a meaningful improvement over many previously reported sulfur polymers rather than complete parity with inorganic optics. Their glass transition temperature was measured at approximately 115 °C, sufficiently high to maintain stable lens shapes with no deformation under typical thermal imaging usage conditions.

The lenses demonstrated a high refractive index and low absorbance across the LWIR band, essential for efficient thermal imaging applications. Optical testing confirmed the lenses’ capability to capture high-quality thermal images of room temperature subjects, including both LWIR window demonstrations (e.g., using FLIR E6) and full lens replacement experiments in a FLIR Lepton 3.5 module.

In lens-based imaging tests, the polymer optics achieved noise equivalent temperature difference (NETD) values of ~62–63 mK, compared to ~53.6 mK for a commercial silicon doublet under the same conditions, indicating competitive but not yet superior performance.

Reactive compression molding proved highly effective for rapid, scalable production of arrays of lenses while preserving optical clarity and performance comparable to conventionally cast lenses. This molding approach also facilitates recycling of off-cuts and damaged lenses, providing a sustainability advantage over germanium and silicon optics, which are not easily recyclable. The successful demonstration of these lenses on commercially relevant camera modules substantiates their potential to complement and partially replace conventional infrared lenses in diverse applications.

The material’s dynamic sulfur-sulfur bonds endow it with processability benefits uncommon in inorganic infrared optics. This sulfur polymer’s high thermal stability, combined with its infrared transparency, enables complex lens architectures to be envisaged in the future, including diamond-turned surfaces for improved image quality and integration of gradient refractive index structures by surface sulfur concentration variation. These concepts are proposed as future research directions rather than demonstrated capabilities in the present study. Such innovations could reduce the need for conventional antireflective coatings, which tend to peel over time. These findings open pathways to sustainable, low-cost, and high-performance infrared optics fabrication.

Toward Scalable, Recyclable Alternatives

This study presents the first successful synthesis, experimental validation, and device-level demonstration of a previously predicted sulfur-rich polymer optimized for infrared optics. By overcoming prior synthetic limitations and demonstrating compatibility with commercial thermal imaging systems, the work establishes a promising foundation for scalable, recyclable infrared optical materials. While further optimization is required to match or exceed the performance of established inorganic optics, the approach highlights a viable pathway toward more sustainable and manufacturable LWIR imaging technologies.
