Optical telescopes are essential tools in astronomy, built to collect and focus light from distant celestial objects. By capturing and concentrating photons onto a detector, these instruments allow for detailed imaging and analysis of the universe. Optical telescopes rely on two key physical principles to focus light: refraction, the bending of light as it passes through a curved lens, and reflection, the redirection of light off a curved mirror. Various types of optical telescopes make use of these principles, each designed to enhance our view of the cosmos and bring distant objects into clearer focus.
Image Credit: Jose J Horcajo/Shutterstock.com
Refracting Telescopes (Refractors)
Lenses are used by refractors, also known as refracting telescopes, to gather and focus light.1,2,3 The principle of refraction, which states that light bends when it passes from one medium (air) into another (glass), is the foundation of this process. The angle at which light strikes the lens surface and the material's index of refraction determines how much bending occurs. It is possible to bring incident light to a single focus point by curving the lens surfaces to resemble a sphere. Nevertheless, chromatic aberration remains a major limitation of refracting telescopes. Because the index of refraction varies with wavelength, different colors of light bend by different amounts, causing the final image to appear with color fringes or a muddied appearance. Even with advanced optical corrections, refractors face significant practical challenges in fully eliminating these blurring effects.
Reflecting Telescopes (Reflectors)
For professional astronomy, reflecting telescopes, often known as reflectors, have proven to be much more effective and adaptable.1,2,3 They function according to the basic principle that the angle of incidence and angle of reflection are equal. A big, curved mirror, usually formed like a conic section, is used to focus light. Regardless of where light strikes the mirror, this form guarantees that light coming from a source at an unlimited distance is brought to a precise focus. Reflecting telescopes are well-suited for broad-spectrum observation because they inherently avoid chromatic aberration, as reflection affects all wavelengths of light equally. This advantage makes them ideal for capturing clear images across a wide range of the electromagnetic spectrum. The same design principle is also used in radio and X-ray telescopes, where precise reflection is essential for accurate data collection.
The Newtonian reflector, created by Sir Isaac Newton, is the most basic type of reflector.2 It directs light to an eyepiece positioned at the side of the telescope barrel using a flat secondary mirror and a parabolic primary mirror. Today, this design is mostly used by amateur astronomers.
Cassegrain telescopes, a variant of the reflecting telescope, dominate professional astronomy because they reduce visual obstructions and allow stable mounting of large instruments behind the primary mirror.3 The classic design uses a concave parabolic primary mirror and a convex secondary mirror to refocus light through a central aperture. A popular variation, the Ritchey-Chrétien, employs hyperbolic mirrors to minimize aberrations across wide fields. Another variation, the coudé focus, uses a third flat mirror to direct light to a fixed position, typically to accommodate heavy or stationary instruments. While this setup was more common in the past, it's used less frequently today thanks to the development of lightweight electronic detectors.
Reflecting telescopes can still experience coma, an optical distortion that causes off-axis stars to appear stretched or comet-like. However, modern optical correction techniques are effective at minimizing this issue, preserving image quality even at the edges of the field of view.
Catadioptric Telescopes (Compound Designs)
In order to produce better imaging performance, over a larger field of view, catadioptric telescopes include both reflective mirrors and refractive lenses.3 A well-known example of a catadioptric design is the Schmidt telescope. While spherical primary mirrors naturally introduce significant aberration and distortion, they are ideal for wide-field sky surveys due to their geometric simplicity and broad coverage. The Schmidt design addresses these distortions by placing a large, specially shaped refractive corrector plate at the telescope’s aperture. This plate intentionally introduces chromatic aberration in the opposite direction of the mirror's distortion, effectively canceling out the effect. The result is a sharp, accurately colored image across a wide field of view, making it highly effective for surveying large areas of the sky.
Specialized and Niche Optical Telescope Designs
The challenges of manufacturing and maintaining large, single-piece primary mirrors, particularly achieving extremely smooth surfaces and preventing the mirror from sagging under its own weight, have driven the development of innovative new technology telescope (NTT) designs. These modern approaches aim to overcome the physical and engineering limitations of traditional mirrors, enabling larger and more precise telescopes without compromising structural integrity or image quality.
One important strategy is to create the appearance of a single, considerably bigger aperture by employing several or segmented mirrors. Using six distinct primary mirrors placed in a hexagonal configuration, the Multiple Mirror Telescope (MMT) was a groundbreaking design that achieved the collecting area of a considerably larger single mirror by perfectly merging the pictures. This achievement required a sophisticated, highly accurate optical alignment mechanism.
The 10-meter Keck Memorial Telescope in Hawaii is an example of a segmented-mirror telescope, which is a more common design. Each of the thirty-two hexagon-shaped pieces that make up the Keck primary mirror is installed on an electrically powered actuator. The position and tilt of each piece are continuously measured and adjusted many times per second using laser rangefinders and computers. In order to precisely counteract the distorting effects of Earth's atmosphere and present a cleaner wavefront to the detector, this system, known as adaptive optics, effectively modifies the mirror's form in real-time. The resolution limit imposed by atmospheric turbulence has improved thanks in large part to this technical advancement.
Applications in Astronomy and Beyond
From ground-based observation to satellite-based astronomy, optical reflector telescopes have been the main instruments for studying the cosmos. The most major achievement in optical astronomy was the launch of the Hubble Space Telescope (HST) in 1990. The HST's orbit above the atmosphere removed the effects of atmospheric absorption and blurring, enabling the use of a far wider range of light, from ultraviolet to infrared.
Beyond astronomy, telescopic instruments serve diverse purposes across multiple fields. For terrestrial viewing, binoculars and spotting scopes enable wildlife observation without disturbance, while compact telescopes integrated into riflescopes support many types of reconnaissance. In industry and research, optical telescopes are vital for surveying, geodesy, metrology, and quality control, while adaptive optics, originally developed for astronomy, now improves retinal imaging and advanced microscopy. Defense and security applications include surveillance, target acquisition, satellite tracking, and night vision systems, as well as optical components in heads-up displays for vehicles and aircraft.5
Industrial and Technological Developments
The ongoing interaction between optical design and advancements in materials and control systems has defined the history of modern telescope development. The 1970s and 1980s saw giant leaps in optical astronomy thanks to advancements in electronics and mechanical engineering. Complex multimirror and segmented-mirror systems may now be designed and maintained in alignment thanks to the advent of sophisticated computerized control systems. Moreover, instrumentation was transformed with the development of the charge-coupled device (CCD), an extremely sensitive electronic detector. Compared to earlier film-based techniques, CCDs allowed for considerably fainter objects to be studied in a given amount of time, created images that could be altered by computers, and allowed for direct brightness measurements. CCDs' great sensitivity made it possible to use computational methods to account for atmospheric distortion.6
Future Trends in Optical Telescope Design
Future developments in optical telescope design will concentrate on advanced electromechanical and computational methods to mitigate atmospheric distortion. Adaptive optics, for example, measures the distortion of a real star's picture or creates an artificial "guide star" by beaming lasers into the atmosphere. After that, a computer examines the return signal to determine a correcting method that can be utilized in real time to modify the primary mirror's form or the CCD image. This method depends on contemporary computers and actuators that can adapt to the atmosphere's quick fluctuations.
Speckle-cell interferometry, which views the atmosphere as the first optical element whose distortion may be computationally negated, was developed as a result. The next generation of incredibly huge telescopes is promised by the combination of many segmented-mirror telescopes for even higher light-gathering potential, which is still a major proposal for the upcoming decades.
Interested in other types of telescopes? Check the full guide here
Reference and Further Reading
- Dooling, D. (2022) Optical Telescopes [Online] EBSCO Knowledge AdvantageTM. Available at: https://www.ebsco.com/research-starters/science/optical-telescopes
- Krisciunas, Kevin. "Astronomical centers of the world." Cambridge: University Press (1988).
- Editorial Feature. (December 1 2007) Optical Telescope - How Does it Work? [Online] AZOOptics. Available at: https://www.azooptics.com/Article.aspx?ArticleID=81#:~:text=The%20magnification%20of%20a%20telescope%20is%20performed,the%20image%20appears%20larger%20to%20the%20observer.
- Draganov, V and Bandera, P (September 2004) Compact Telescope Design Suited to Military and Commercial Applications [Online] Photonics Spectra. Available at: https://www.photonics.com/Articles/Compact-Telescope-Design-Suited-to-Military-and/a19919
- Kim, Dae Wook, Marcos Esparza, Henry Quach, Stephanie Rodriguez, Hyukmo Kang, Yi-Ting Feng, and Heejoo Choi. "Optical technology for future telescopes." In Fourth International Conference on Photonics and Optical Engineering, vol. 11761, pp. 9-18. SPIE, 2021.
