A recent study published in the journal Advanced Photonics Research investigated the nonlinear optical properties of semiconductor-metal nanocavities using second and third-harmonic generation (SHG and THG) microscopy. Researchers investigated how embedding gallium arsenide (GaAs) nanopillars in a gold matrix affects the intensity and spatial distribution of nonlinear optical signals.
Image Credit: IM Imagery/Shutterstock.com
The findings offer valuable insights into light-matter interactions at the nanoscale and highlight the potential for high-resolution, label-free imaging.
Importance of Nanocavities in Photonics
Semiconductor nanocavities play a critical role in controlling light at subwavelength scales, enabling strong light-matter interactions that are essential for applications such as nonlinear optics and integrated photonic circuits. Hybrid metal-semiconductor nanocavities boost optical confinement and nonlinear effects by merging the high-quality factors of dielectric materials with the strong field confinement capabilities of metals. This approach addresses limitations of conventional dielectric nanocavities, which struggle to minimize mode volumes.
Reliable non-invasive characterization is still a challenge despite advancements in fabrication techniques. Electron microscopy offers high spatial resolution but is invasive and limited to surface analysis. Nonlinear optical microscopy techniques provide a non-destructive, high-resolution imaging, making them ideal for probing embedded nanocavities.
Investigating Hybrid Nanocavities Using Nonlinear Optical Microscopy
Researchers explored two sample types: (1) isolated GaAs nanopillars on a GaAs substrate (Sample A) and (2) GaAs nanopillars partially embedded in a gold film (Sample B). Both samples were fabricated using molecular-beam epitaxy to grow semiconductor layers, followed by electron-beam lithography (EBL) to pattern nanopillars with a 2 μm period, 115 nm diameter, and 200 nm height. Inductively coupled plasma reactive-ion etching formed vertical sidewalls. For Sample B, a 500 nm gold layer was deposited at a 45° angle via electron-beam evaporation, embedding the nanopillars within the metal.
The GaAs substrate was removed through selective chemical etching, leaving the nanopillars embedded in a gold film adhered to an indium phosphide (InP) carrier. The gold layer was thicker than its skin depth, ensuring effective optical confinement and minimizing light leakage.
Nonlinear microscopy was performed using a custom-built scanning system equipped with a femtosecond laser (1060 nm, 80 MHz, 140 fs). A high numerical aperture objective (NA = 0.8) was used for both excitation and signal collection, with photomultiplier tubes detecting SHG (532 ± 9 nm) and THG (356 ± 15 nm) signals. Raster scans in transverse and longitudinal planes were conducted at 0.1 μm steps and controlled power levels (5 mW at 1060 nm, 1.2 mW at 710 nm). COMSOL Multiphysics simulations modeled reflectance spectra and electromagnetic field distributions, showing a nanocavity resonance near 350 nm in Sample B, indicating enhanced field localization within the nanopillars.
Key Findings and Implications
For Sample A (bare GaAs nanopillars), both SHG and THG signals were strong, with SHG showing quadratic and THG cubic dependence on excitation intensity, consistent with nonlinear optical theory. Spatial mapping indicated a clear contrast between nanopillars and the substrate, confirming that the intrinsic nonlinear response of GaAs was enhanced by the nanopillar geometry and its zincblende crystal symmetry.
In contrast, Sample B (GaAs nanopillars embedded in gold) showed different behavior. At a 1060 nm excitation wavelength, the SHG signal (530 nm) displayed poor contrast and was dominated by the gold film’s nonlinear response due to the mismatch between the SHG wavelength and nanocavity resonance. However, the third-harmonic generation (THG) signal at 353 nm matched the nanocavity resonance, resulting in strong contrast and allowing clear visualization of the nanopillar arrays, despite the metallic environment.
Longitudinal scanning demonstrated that SHG signals from the embedded nanopillars were present but masked in transverse scans by the stronger response from the gold substrate. To enhance SHG contrast, the excitation wavelength was tuned to 710 nm, shifting the SHG emission to 355 nm, closer to the nanocavity resonance, which significantly improved visibility.
Significance for Nanophotonics
This research advances the understanding of nonlinear optical phenomena in hybrid nanocavities, which are key components for next-generation photonic devices. The ability to non-invasively image and characterize semiconductor nanostructures embedded in metallic environments is essential for developing ultra-compact lasers, nonlinear optical switches, and integrated photonic circuits with enhanced light-matter interaction.
By demonstrating how nonlinear optical microscopy differentiates nanocavity resonances and spatially resolves individual nanopillars within a reflective gold matrix, the study offers a powerful characterization method. This approach preserves the optical properties of nanostructures and helps in designing devices with improved performance.
The findings have broad implications across photonics, enabling more efficient designs for lasers, sensors, and light-emitting devices. The demonstrated techniques are also applicable to various nanostructured materials, supporting innovative applications in biomedical imaging, materials science, and nanotechnology.
Conclusion and Future Directions
Embedding semiconductor nanocavities within metal films effectively shapes their nonlinear responses, exhibiting strong sensitivity to excitation wavelengths aligned with cavity resonances. THG microscopy provided clear visualization when the harmonic wavelength aligned with the resonance, while SHG contrast could be recovered by adjusting the pump wavelength. These results underscore the value of nonlinear optical microscopy as a tool for probing nanostructures in complex environments.
Overall, this study provides valuable insights into the design and optical characterization of semiconductor-metal nanocavities, laying a foundation for developing advanced nanophotonic devices with enhanced performance. Future work should explore polarization-resolved imaging and alternative material systems to further harness the unique properties of these hybrid structures for applications in quantum optics and integrated photonics.
Disclaimer: The views expressed here are those of the author expressed in their private capacity and do not necessarily represent the views of AZoM.com Limited T/A AZoNetwork the owner and operator of this website. This disclaimer forms part of the Terms and conditions of use of this website.
Source:
Journal Reference
Varghese, R., & et al. (2025). Nonlinear Optical Microscopy of Semiconductor-Metal Nanocavities. Advanced Photonics Research, 2500114. DOI: 10.1002/adpr.202500114, https://advanced.onlinelibrary.wiley.com/doi/10.1002/adpr.202500114
