Compact HD Lens for Aviation Applications

Resolve Optics Ltd. has developed a new rugged High Definition (HD) lens optimised for use in Head-Up Display (HUD) systems.

Image Credit: Resolve Optics

Lenses for today’s HUD system are more likely to be used to capture images of the pilots view out of the cockpit with the symbology over laid on the final image as opposed to the lens looking through the combiner and capturing the symbology at the same time as the pilot’s view. No matter which technology is used there is still the issue of each aircraft type needing a different field of view (FOV). This has traditionally required a different optical lens design for each aircraft type which can be very costly both in terms of optical design costs and qualification of each lens/camera system.

Resolve Optics has taken the approach of designing a small compact zoom design that covers the majority of the aircraft that require HUD system recording. The zoom design can be used to set the lens at a desired FOV and locked. This means no matter what aircraft you need a HUD system for you will already have an optimised lens that can accommodate the correct FOV. Resolve Optics HD HUD lens has been designed and tested to withstand the high levels of vibration, shock typically found in aircraft.

For further information about standard resolution and high-definition HUD zoom lenses please contact Resolve Optics on +44-1494-777100 or [email protected]. To read a HUD camera lens development case study please visit https://www.resolveoptics.com/compact-rugged-head-up-display-camera-lens/.

Drawing upon nearly 30-years experience - Resolve Optics has built a strong reputation for specialist lens design and manufacture of production quantities of lenses and optical products on time to strict quality and target price guidelines.
