Promising New Method to Boost Fiber Optic Data Rates

In an increasingly data-driven world where everything from cell phones to cities are getting “smarter,” demand for Internet data traffic capacity continues to soar. But it will become harder and harder to meet that demand unless new approaches emerge to dramatically increase the bandwidth, or amount of data per second that can be transmitted across the network’s communications channels.

Professor Siddharth Ramachandran (ECE) has demonstrated a promising new way to boost fiber optic data rates considerably that exploits donut-shaped laser light beams called optical vortices. In an optical vortex, the light twists like a tornado as it moves along the beam path, rather than in a straight line.

Now a new fiber optic technology developed by Professor Siddharth Ramachandran (ECE) offers hope of increasing bandwidth considerably, enabling Internet providers to offer much greater connectivity – from decreased network congestion to on-demand video streaming – at a comparable cost.

Described in the June 28 issue of the journal Science, the technology centers on donut-shaped laser light beams called optical vortices, in which the light twists like a tornado as it moves along the beam path, rather than in a straight line. Widely studied in molecular biology, atomic physics and quantum optics, optical vortices (also known as orbital angular momentum (OAM) beams) were thought to be unstable in fiber, until Ramachandran recently designed an optical fiber that can propagate them. In the paper, he and collaborators from University of Southern California, OFS-Fitel (a fiber optics company in Denmark) and Tel Aviv University demonstrate not only the stability of the beams in optical fiber but also their potential to boost Internet bandwidth.

“For several decades since optical fibers were deployed, the conventional assumption has been that OAM-carrying beams are inherently unstable in fibers,” said Ramachandran. “Our discovery, of design classes in which they are stable, has profound implications for a variety of scientific and technological fields that have exploited the unique properties of OAM-carrying light, including the use of such beams for enhancing data capacity in fibers.”

Funded by the Defense Advanced Research Projects Agency under the Information in a Photon (InPho) program, the technology could not come at a better time, as one of the main strategies to boost Internet bandwidth is running into roadblocks just as mobile devices fuel rapidly growing demands on the Internet. Traditionally, bandwidth has been enhanced by increasing the number of colors, or wavelengths of data-carrying laser signals—essentially streams of 1s and 0s—sent down an optical fiber, where the signals are processed according to color. Increasing the number of colors has worked well since the 1990s when the method was introduced, but now that number is reaching physical limits.

An emerging strategy to boost bandwidth is to send the light through a fiber along distinctive paths, or modes, each carrying a cache of data from one end of the fiber to the other. Unlike the colors, however, data streams of 1s and 0s from different modes mix together; determining which data stream came from which source requires computationally and energy-intensive digital signal processing algorithms.

Ramachandran’s approach combines both strategies, packing several colors into each mode, and using multiple modes. Unlike in conventional fibers, OAM modes in these specially designed fibers can carry data streams across an optical fiber while remaining separate at the receiving end. In experiments appearing in the Science paper, Ramachandran and his collaborators created an OAM fiber with four modes (an optical fiber typically has two), and showed that for each OAM mode, they could send data through a one-kilometer fiber in 10 different colors, resulting in a transmission capacity of 1.6 terabits per second.

That’s the equivalent of being able to transmit eight Blu-RayTM DVDs every second.
