The pinhole camera, an ancient device consisting of nothing more than a dark box with a small aperture, is often celebrated as the simplest embodiment of optical imaging. Once used primarily for educational demonstrations, the pinhole’s principle is now inspiring a wave of innovation in infrared (IR) imaging.1
Image Credit: DARUNEE SAKULSRI/Shutterstock.com
Advances in computational optics, metasurfaces, and calibration techniques are enabling researchers to overcome the classic trade-offs of sharpness and brightness, breathing new life into the pinhole model.
This revival is not just nostalgic; it is practical. As modern industries demand ever smaller, cheaper, and more robust imaging systems, lensless infrared designs provide an appealing alternative. The renewed relevance of the pinhole principle stems from both miniaturization needs and material science advances, which together make it possible to reimagine the camera’s simplest form for today’s most complex imaging challenges.1
Download the PDF of the article
Why Infrared Imaging Needs a New Approach
Infrared imaging has expanded far beyond its early niche applications to become a cornerstone of modern technology. It now underpins defense and security systems through night vision and missile tracking, advances medical diagnostics in areas such as vascular health and wound monitoring, enables autonomous vehicles to operate in poor visibility, and supports remote sensing of crops and climate from orbit.2
Market reports consistently highlight the sector’s rapid growth, but progress is often slowed by the high costs and technical challenges of conventional infrared cameras. Traditional systems rely on lenses made from germanium or chalcogenide glass, materials that are expensive, heavy, and fragile. These characteristics make them poorly suited for lightweight platforms such as drones or wearable devices.3
Adding to the challenge, many infrared detectors require cryogenic cooling to minimize thermal noise, an approach that increases system size, power consumption, and overall cost. These factors continue to limit the wider adoption of infrared technology, despite its clear value. In this context, the renewed interest in the pinhole principle presents a promising alternative: a lensless, calibration-based approach that lowers component complexity, streamlines system design, and makes infrared imaging more accessible for cost-sensitive applications.2
The Pinhole Principle Meets Modern Engineering
The classic pinhole camera works by allowing light rays to pass through a small aperture and form an inverted image on a detection plane. While this design ensures perfect depth of field, its resolution and brightness have historically been limited, preventing it from competing with refractive optics. Modern engineering, however, is transforming this ancient principle into a powerful tool for infrared imaging.1, 4
Advances in computational imaging and metasurface technology now make it possible to replace bulky glass lenses with coded apertures or diffractive patterns, while machine learning algorithms reconstruct high-resolution images from the encoded light fields. Recent demonstrations by A. ElSheikh et al. confirm that metasurface-based pinhole arrays can precisely manipulate mid-infrared wavelengths, producing sharp reconstructions without the need for conventional optics.2
Geometric calibration is equally important. Techniques based on the pinhole approximation have demonstrated that emissivity-engineered checkerboard targets, produced using UV printing or laser engraving, can achieve reprojection errors as low as 0.057 pixels.2
Together, these developments demonstrate that a minimalist, lensless architecture, once viewed as a constraint, can now deliver reliable spatial accuracy and image quality when paired with modern mathematics, nanofabrication, and calibration science.
From Lab to Market: Emerging Commercial Applications
The transition from laboratory research to real-world deployment is already in motion, with startups and research spinoffs actively pursuing lensless infrared sensors designed for compact and distributed sensing. Defense contractors envision lighter reconnaissance payloads where reduced lens bulk enables drones to carry infrared systems without sacrificing flight endurance, while consumer electronics companies are investigating ways to embed miniature infrared modules into wearables and IoT devices.3
Potential applications span compact drone surveillance, where streamlined payloads enhance efficiency; wearable medical monitors, such as patches or wristbands capable of continuously tracking skin temperature or circulatory conditions; and smart infrastructure, where minimalist infrared nodes integrated into buildings, vehicles, and factories provide scalable, low-cost thermal awareness.5
The advantages are clear: eliminating heavy lenses and reducing the need for cryogenic cooling drive down both cost and system complexity. For consumer markets in particular, this democratization is transformative, opening the possibility that pinhole-inspired infrared imaging could soon become as ubiquitous as accelerometers or cameras in smartphones.3
Technical Challenges and Research Frontiers
Despite significant advances, pinhole-inspired infrared imaging still faces important limitations. The small apertures that define pinhole systems inherently restrict light throughput, leading to reduced sensitivity, while image resolution typically lags behind that of conventional refractive optics. In addition, the precise alignment required for metasurfaces or coded apertures introduces fabrication complexity, which can hinder scalability.6
To overcome these barriers, researchers are exploring several promising directions. For instance, Sung et al. reported that machine learning reconstruction techniques, powered by neural networks trained on large thermal datasets, can enhance image sharpness and compensate for weak signals.7
Calibration breakthroughs, such as emissivity engineered checkerboard targets fabricated with UV printing or laser engraving, have achieved record low reprojection errors, providing highly accurate geometric mapping.8 At the same time, integrating photonic crystals into metasurfaces enhances both light throughput and spectral selectivity, which could bring about higher-quality and more adaptable imaging solutions.
Minimalist Optics for a Smarter Infrared Future
The next five to ten years are likely to bring a profound transformation in the way infrared imaging is designed and deployed. Miniaturization will drive widespread adoption of chip-scale IR modules integrated into wearables, smartphones, and household devices, making thermal sensing as common as cameras or GPS.3
At the same time, combining minimalist optical designs with quantum-enhanced IR detectors holds the potential to revolutionize astronomy, defense, and secure communications by delivering unprecedented sensitivity and precision.
In space exploration, light weight and low power pinhole based infrared imagers could extend thermal sensing to planetary probes, where mass and energy efficiency are critical. Meanwhile, advances in artificial intelligence, particularly in computational reconstruction and deep learning, will continue to enhance image fidelity, enabling clear results even from sparse optical data.1
Collectively, these developments underscore a decisive shift toward ultra-compact, AI-enhanced imaging systems, where the revival of the pinhole principle not only reaffirms its historical significance but also promises to redefine how humanity perceives the invisible thermal world.
Infrared light plays a big role in spectroscopy - find out how here
References and Further Studies
- Li, Y.; Huang, K.; Fang, J.; Wei, Z.; Zeng, H., Mid-Infrared Nonlinear Pinhole Imaging. Optica 2025, 12, 1478-1485.
- ElSheikh, A.; Abu-Nabah, B. A.; Hamdan, M. O.; Tian, G.-Y., Infrared Camera Geometric Calibration: A Review and a Precise Thermal Radiation Checkerboard Target. Sensors 2023, 23, 3479.
- Yu, Y., Technology Development and Application of Ir Camera: Current Status and Challenges. Infrared Millim. Wave 2023, 1, 1-7.
- Huang, K.; Fang, J.; Yan, M.; Wu, E.; Zeng, H., Wide-Field Mid-Infrared Single-Photon Upconversion Imaging. Nature communications 2022, 13, 1077.
- Altaf, M. A.; Ahn, J.; Khan, D.; Kim, M. Y., Usage of Ir Sensors in the Hvac Systems, Vehicle and Manufacturing Industries: A Review. IEEE Sensors Journal 2022, 22, 9164-9176.
- Li, S.; Gao, Y.; Wu, J.; Wang, M.; Huang, Z.; Chen, S.; Cao, L., Lensless Camera: Unraveling the Breakthroughs and Prospects. Fundamental Research 2025, 5, 1725-1736.
- Sung, W.-T.; Lin, C.-H.; Hsiao, S.-J., Image Recognition Based on Deep Learning with Thermal Camera Sensing. Comput. Syst. Sci. Eng. 2023, 46, 505-520.
- Sun, S.; Wei, W.; Yuan, X.; Zhou, R., Research on Calibration Methods of Long-Wave Infrared Camera and Visible Camera. Journal of Sensors 2022, 2022, 8667606.
