Physical and Mechanical Properties of Silicon (SiO2) by Insaco

Silicon is the second most abundant element on Earth. It is produced by the reduction of silica (SiO2). The main commercial applications for silicon are in semiconductors and solar cells.

Image Credit: Shutterstock/Sadovnikova Olga

Chemical Formula of Silicon

The chemical formula of Silicon is provided in the table below:

Property Value*
Chemical Formula Si

* All properties are at room temperature unless otherwise noted.

Mechanical Properties of Silicon

The mechanical properties of Silicon are mentioned in the table below:

Property Value*
Density 2.33 gm/cc
Hardness 1150 Knoop
Tensile Strength 113 MPa
Modulus of Elasticity 112 GPa(Young's)
Flexural Strength ~300 MPa
Poisson's Ratio 0.28
Fracture Toughness 3-6 MPa m1/2

* All properties are at room temperature unless otherwise noted.

Electrical Properties of Silicon

The electrical properties of Silicon are mentioned in the table below:

Property Value*
Dielectric Constant 11.8(@ 1 MHz)
Volume Resistivity 10-3 ohm-cm

* All properties are at room temperature unless otherwise noted.

Thermal Properties of Silicon

The thermal properties of Silicon are mentioned in the table below:

Property Value*
Coefficient of Thermal
Expansion
2.6 x 10-6/°C
Thermal Conductivity 156 W/mK
Specific Heat 0.15 cal/g°C
Maximum Working Temperature 1350°C

* All properties are at room temperature unless otherwise noted.

Optical Properties of Silicon

The optical properties of Silicon are mentioned in the table below:

Property Value*
Index of Refraction 1.54
Transmission Band 0.30-37 Wavelength
(microns)
In the IR range

* All properties are at room temperature unless otherwise noted.

About Inasco

Since 1947, Insaco has been synonymous with excellence in the development and production of high precision machined parts. As a custom fabricator of ceramic, glass, sapphire, and other hard materials, Insaco specializes in machining parts that often require tolerances measured in millionths of an inch, and wear properties that satisfy even the most demanding applications.

This information has been sourced, reviewed and adapted from materials provided by INSACO Inc.

For more information on this source, please visit INSACO Inc.
