Original Equipment Manufacturing (OEM) Solutions for Image Processing

About EyeVision Technology’s OEM Solutions

Due to consumer demand, EyeVision Technology (EVT) has designed a number of sensor-, CPU- and I/O-boards, as well as OEM systems that have a multitude of different applications. EVT OEM solutions include hardware platforms and libraries, as well as the standard software offered by EVT.

IoCap (Image Capture & IO) Board

The IoCap Board includes the following features:

  • 4 in- and 4 outputs
  • 12-24 V I/O input voltage
  • Gigabit Ethernet
  • 2 camera interfaces, which:
    • allow for remote control
    • can be combined with all EVT and/or customer sensor boards
  • All EyeMIO characteristics

EyeMIO – PLC-IO-Module

PLC-IO-modules have been specifically designed for industrial use. When utilized in conjunction with the EyeVision software, these modules act as an interface between the image processing system and production plant. Some features of these modules include:

  • 4 in- and 4 outputs
  • Available interfaces:
    • RS232 (can be configured via USB)
    • USB
    • Ethernet
  • 24 V connector

ZYNQ Boards

EVT currently offers two types of ZYNQ board:

  • Raze1-15 with 74 k Logic Elements
  • Raze1-30 with 125 k Logic Elements

Features of EVT’s ZYNQ board includes:

  • XILNX ZYNQ SoC FPGA
  • 64 MB QPSI flash
  • 8 GB flash
  • Available interfaces:
    • GigE
    • USB
    • Digital I/O

ARM Boards

Features of EVT’s ARM board includes:

  • QuadCore 1,5 GHz CPU
  • OctaCore 2 GHz CPU
  • 8 GB flash
  • Digital I/O
  • Available interfaces:
    • GigE
    • USB
    • HDMI

Sensor Head with Small Robot

Original Equipment Manufacturing (OEM) Solutions for Image Processing

IoCap (Image Capture & IO) Board - Picture 1
IoCap (Image Capture & IO) Board - Picture 2
IoCap (Image Capture & IO) Board - Picture 3
IoCap (Image Capture & IO) Board - Picture 4
EyeMIO – PLC-IO-Module - Picture 1
EyeMIO – PLC-IO-Module - Picture 2
EyeMIO – PLC-IO-Module - Picture 3
EyeMIO – PLC-IO-Module - Picture 4
ZYNQ Boards
