High Precision Multi-Axis Motion with Hexapod 6-Axis Systems - New 130 Page PI Catalog

PI's new 130 page catalog provides background information and features a variety of Hexapod (Stewart-Platform) motion and positioning systems with 6 degrees of freedom and high resolution and repeatability in the sub-micrometer and even nanometer range.

Hexapods are available with travel ranges from ½ inch to several hundred millimeters and load ranges from 0.5kg to several tons. Hexapods can be optimized for high load, high precision and high speed.

Depending on the load, speed, and precision class, electrodynamic, electromechanical or piezoelectric drives are employed. High-speed, direct-drive hexapods are used for motion simulation applications from reproducing hand tremors for camera stabilization to ship motion analysis.

Software and & Hexapod Motion Controllers


All PI hexapods shown in the new catalog are operated with dedicated state-of-the-art motion controllers and software. The required coordinate transformations are handled inside the controller and are transparent to the user - all motions are programmed in XYZ linear coordinates and Theta-X, Theta-Y, and Theta-Z Rotations. In addition, user defined coordinate systems and a user programmable center of rotation (pivot point) enhance the usability.

Application examples of hexapod Stewart platforms include precision automated alignment in optics, photonics, medical design, robotics, aeronautics and astronomy, camera lens manufacturing, etc.

Standard and Custom

PI has in-house engineered solutions with over 4 decades of experience working with customers to provide products that meet application demands, and can quickly modify existing product designs or provide a fully customized OEM part to fit the exact requirements of the application.

USA / Canada

https://www.pi-usa.us/en|[email protected]

East

(508) 832-3456

Midwest

(508) 832-3456

West

(949) 679-9191 (LA Area & Mexico)

(408) 533-0973 (Silicon Valley/Bay Area)
