Spectroscopic Ellipsometers

Ellipsometry is a versatile and powerful optical technique for the investigation of the dielectric properties (complex refractive index or dielectric function) of thin films. It has applications in many different fields, from semiconductor physics to microelectronics and biology, from basic research to industrial applications. Ellipsometry is a very sensitive measurement technique and provides unequalled capabilities for thin film metrology. As an optical technique, spectroscopic ellipsometry is non-destructive and contactless.

Request a Quote for Spectroscopic Ellipsometers

If you'd like us to help you source a Quotation for Spectroscopic Ellipsometers please click here. Once submitted, we will try and place you in contact with a suitable Spectroscopic Ellipsometers supplier within 48 hours.

Equipment

J.A. Woollam alpha-SE Spectroscopic Ellipsometer

For routine measurements of thin film thickness and refractive index, the alpha-SE® is a great solution. Designed for ease-of-use: simply mount a sample, choose the model that matches your film, and press measure. You have results within seconds.

SOPRA IRSE5E Infra Red Ellipsometer

SOPRA has developed a Stand alone Fourier Transform Infra-Red Spectroscopic Ellipsometer (FTIR-SE) covering spectral range from 1.5µm to 17 µm (550 cm-1) as standard using highly sensitive MCT detector and to 33µm using Optional DTGS detector and special optics. The Infra Red ellipsometer can measure without contact and reference sample at atmopheric pressure and can be easely implemented in in-situ applications

SpecEl-2000-VIS Ellipsometer from Ocean Optics

The SpecEl-2000-VIS Ellipsometer measures polarized light reflected from the surface of a substrate to determine the thickness and refractive index of the material as a function of wavelength. You can measure refractive index, absorbance and thickness with the touch of a button. In SpecEl Software, you can configure and save experiment method files for one-step analysis.

J.A. Woollam IR-VASE Spectroscopic Ellipsometer

The IR-VASE® is the first and only spectroscopic ellipsometer to cover the spectral range from 2 to 30 microns (333 to 5000 wavenumbers). The IR-VASE can determine both n and k for materials over the entire width of the spectral range without extrapolating data outside the measured range, as with a Kramers-Kronig analysis. Like other Woollam ellipsometers, the IR-VASE is perfect for thin films or bulk materials including dielectrics, semiconductors, polymers, and metals.

J.A. Woollam M-2000-Series Spectroscopic Ellipsometers

The M-2000 line of spectroscopic ellipsometers is engineered to meet the diverse demands of thin film characterization. An advanced optical design, wide spectral range, and fast data acquisition make it an extremely powerful and versatile tool. The M-2000 delivers both speed and accuracy. Our patented RCE technology combines Rotating Compensator Ellipsometry with high-speed CCD detection to collect data from the entire spectrum (hundreds of wavelengths) in a fraction of a second with a wide array of configurations.

SOPRA GES5E PUV Spectroscopic Ellipsometer

SOPRA produces a Spectroscopic Ellipsometer capable to work down to 135 nm. The entire spectral range is 135-650 nm. This enable to measure all the new materials designed for the next generation lithography (157 nm, Fe excimer laser), like photoresist, ARC layers and all the optics included in the next generation Stepper.

SOPRA GES5E Spectroscopic Ellipsometer

The GES5E is the SOPRA core instrument for R&D applications. GES5E integrates advanced and well proven opto-mechanical designs coupled to high performance electronics, Spectrometers and spectrographs and user friendly WindowsTm software. GES5E is the most recent model of 5 generations of spectroscopic ellipsometers developed by SOPRA.
